Dell PowerEdge Servers
Unmatched Performance. Enterprise-Grade Reliability.
Overview
Advanced Security
Protect your data with built-in security features, end-to-end encryption, and trusted boot technology.
Seamless Management
Streamline operations with automated, intelligent management tools like Dell OpenManage.
Energy Efficiency
Reduce operational costs with intelligent thermal management and energy-efficient designs.
Technical details
| Name |  | |
|---|---|---|
| Form Factor | 1U rack server | 2U rack server |
| Processor | One Intel Xeon E-2300 series processor with up to 8 cores | Up to two 3rd Generation Intel Xeon Scalable processors with up to 24 cores per processor |
| Memory | Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s | Sixteen DDR4 DIMM slots, supports RDIMM 1 TB max, speeds up to 2933 MT/s |
| Drive bays | Up to four 3.5-inch SAS/SATA (HDD/SSD) max 30.72 TB | Up to eight 3.5-inch SAS/SATA (HDD/SSD) max 128 TB |
| Front ports | One USB 2.0, one iDRAC Direct (Micro-AB USB) port | One USB 2.0, one VGA, one Dedicated iDRAC (Micro-AB USB) port |
| Rear ports | One USB 2.0, one iDRAC ethernet port, one USB 3.0, one VGA, one Serial port | One USB 2.0, one Serial (optional), one iDRAC ethernet port, one USB 3.0, one VGA |
| PCIe | Two Gen 4 PCIe slots | Three Gen 4 PCIe slots, one Gen3 PCIe slot |
| Dimensions | Height: 1.68 inches, Width: 18.97 inches, Depth: 23.56 inches | Height: 3.41 inches, Width: 18.97 inches, Depth: 28.72 inches |
Gallery
